Emission testing

Qualitative and quantitative determination of volatile organic compounds from building products and indoor air

The following emission test chambers and analytical instruments are used to identify and quantify volatile organic compounds in indoor and test chamber air.

Emission test chambers:

Micro-chamber (µ-CTE)
Emission cell (FLEC)
23 L emission test chambers (glas)
1 m³ emission test chambers (stainless steel)

Analytical instruments:

Gas chromatograph and mass spectrometer with thermal desorption unit (TD-GC/MS)
Gas chromatograph and flame ionization detector with thermal desorption unit (TD-GC/FID)
Ion chromatograph (IC)
Ultra High Performance Liquid Chromatographie (UHPLC)
UV/Vis spectrometer

Photo series

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Christina Waitkus

© Thünen Institut, Christina Waitkus

Gas chromatograph and mass spectrometer with thermal desorption unit for identifying and quantifying volatile organic compounds

GC-MS: Autosampler with thermal desorption tubes

Capillary column in the gas chromatography oven

Engl.: GC-MS-Analysis Software

Clean-Cube for removing impurities of up to 20 thermal desorption tubes

Loading rig for loading thermal desorption tubes with an internal standard (toluol-d8)

Gas chromatograph and flame ionization detector with thermal desorption unit for quantifying volatile organic compounds

Ion chromatograph with autosampler for quantifying volatile carboxylic acids

High-performance liquid chromatograph for quantifying formaldehyde and other carbonyl compounds

UHPLC: Autosampler for up to 108 samples

Gas analysis device for determination of the amount of formaldehyde released by wood-based panels

Gas washing bottles containing water to absorb formaldehyde

Photometrically determination (UV/Vis spectrometer) of the formaldehyde content

Micro-Chamber (µ-CTE) for emission screening of small samples

Micro-Chamber: Simultaneously testing from up to six samples

Micro-Chamber: Loading with different kinds of materials - Emission measurement in relation to surfaces or the whole sample (e.g. toys, pellets)

Field and Laboratory Emission cell (FLEC) for testing emissions from sample surfaces

23 L emission test chamber for measuring formaldehyde and other emissions

1 m³ emission test chamber for measuring formaldehyde and other emissions
